产品概述
描述
This board illustrates a minimal USB PD SINK implementation. It can be used as a small footprint reference design for fast migration from a custom power plug or DC barrel to a USB Type-C® connector.
It is based on the STUSB4531 USB PD controller IC (USB Type-C® rev 2.4, USB PD rev 3.2) and is certified as a “Power Sinking Device” (TID #13956).
-
所有功能
- USB Power Delivery SINK port (up to 100 W)
- Dead battery support
- Short-to-VBUS protection up to 28 V
- Low BOM cost, small footprint
- Status LED
- Certified reference design (board TID: # 13957)
