意法半导体的肖特基和超快速二极管产品系列包括650 至1200 V SiC 以及45 至100 V 场效应整流二极管(FERD),确保设计人员可以利用最新技术 开发具有成本效益的高效转换器/逆变器解决方案。根据目标应用及其电压,开发人员可以从各种设备中进行选择 确保在正向压降((VF))和漏电流方面达到最佳折衷((IR) 以及其他特征。这些二极管和整流器属于STPOWER 系列。



设计人员可以使用我们的波形驱动在线Schottky & FERD eTool 仿真器快速评估最适合其应用的场效应整流器或肖特基二极管。计算机辅助决策功能和强大的搜索引擎使SMPS的设计人员和元件工程师能够迅速、准确地决定哪种场效应整流器或肖特基二极管最适合他们的应用。直观的在线帮助(有中英文两种版本)通过具体示例和快照帮助您入门。
