产品概述
描述
在840-960 MHz UHF频段，ST25RU3993 RAIN® (UHF) RFID读卡器设备提供多协议支持，并与ISO18000-62 & -63、ISO29143和GS1的EPC UHF Gen2空中接口协议兼容。它包括一个片上VCO和一个功率放大器，可提供一整套RFID功能，包括密集读写器模式（DRM）功能，并能支持跳频、低电平传输编码、低电平解码、数据成帧和CRC校验。
ST25RU3993可以极低功率运行，这使其适用于便携式和电池供电的设备，如手机。
ST25RU3993采用7x7 mm QFN封装，具有很高的灵敏度，并能抵抗天线反射和自干扰的影响。这对于移动应用和嵌入式应用非常重要，在这些应用中天线设计常受到成本或尺寸的限制。其高灵敏度使得终端产品在使用更简单更便宜的天线时，也能实现其所需的读取范围，从而可以降低整个系统成本。
由于其高度集成性，ST25RU3993仅需一个外部8位微控制器即可创建完整的RFID读写器系统，因此无需复杂的RFID协处理器。
-
所有功能
- 供电电压范围为3.0至3.6 V
- 有限工作电压可低至2.7 V
- 最大PA供电电压为4.3 V
- 外设I/O电源范围为1.65至5.5 V
- 协议支持：
- ISO 18000-6C（EPC Class1 Gen2）
- ISO 29143（移动RFID的空中接口）
- 直接模式的ISO 18000-6A/B
- DRM：用于M4和M8的250 kHz和320 kHz滤波器
- 集成电源稳压器
- 支持跳频
- ASK或PR-ASK调制
- 自动I/Q选择
- 采用8位线性RSSI的标签跟踪相位位
- 温度范围：-40 °C至85 °C
- 48引脚QFN（7x7x0.9 mm）封装
- 标签读取速度最快可达到700*标签/秒（16位标签EPC长度）
- 供电电压范围为3.0至3.6 V
