产品概述
描述
STM8L050J3 is member of the STM8L ultra-low-power 8-bit family.
STM8L050J3 features an enhanced STM8 CPU core providing increased processing power (up to 16 MIPS at 16 MHz) while maintaining the advantages of a CISC architecture with improved code density, a 24-bit linear addressing space and an optimized architecture for low-power operations.
The STM8L050J3 MCU includes an integrated debug module with a hardware interface (SWIM) which allows non-intrusive In-Application debugging and ultra-fast Flash programming. It features an embedded data EEPROM and low-power, low-voltage, single-supply program Flash memory.
The device incorporates an extensive range of enhanced I/Os and peripherals, a 12-bit ADC, two comparators, a real-time clock, two 16-bit timers, one 8-bit timer, as well as standard communication interfaces such as an SPI, an I2C interface, and one USART.
The modular design of the peripheral set allows this device to have the same peripherals that can be found in different ST microcontroller families including 32-bit families. This makes any transition to a different family very easy, supported also by the use of a common set of development tools.
STM8L050J3 as all the value line STM8L ultra-low-power products are based on the same architecture with the same memory mapping and a coherent pinout.
-
所有功能
- Operating conditions
- Operating power supply: 1.8 V to 3.6 V Temperature range: -40 °C to 125 °C
- Low-power features
- 5 low-power modes: Wait, Low-power run (5.1 µA), Low-power wait (3 µA), Active-halt with RTC (1.3 µA), Halt (350 nA)
- Ultra-low leakage per I/O: 50 nA
- Fast wakeup from Halt: 5 µs
- Advanced STM8 core
- Harvard architecture and 3-stage pipeline
- Max freq: 16 MHz, 16 CISC MIPS peak
- Up to 6 external interrupt sources
- Reset and supply management
- Low power, ultra-safe BOR reset with 5 selectable thresholds
- Ultra-low power POR/PDR
- Programmable voltage detector (PVD)
- Clock management
- 32 kHz and 1 to 16 MHz crystal oscillators
- Internal 16 MHz factory-trimmed RC
- Internal 38 kHz low consumption RC
- Clock security system
- Low-power RTC
- BCD calendar with alarm interrupt
- Digital calibration with +/- 0.5 ppm accuracy
- LSE security system
- Auto-wakeup from Halt w/ periodic interrupt
- 存储器
- 8 Kbytes of Flash program memory and 256 bytes of data EEPROM with ECC
- Flexible write and read protection modes
- 1 Kbyte of RAM
- DMA
- 4 channels supporting ADC, SPI, I2C, USART, timers
- 1 channel for memory-to-memory
- 12-bit ADC up to 1 Msps/4 channels
- Internal reference voltage
- 计时器
- Two 16-bit timers with 2 channels (used as IC, OC, PWM), quadrature encoder
- One 8-bit timer with 7-bit prescaler
- 2 watchdogs: 1 Window, 1 Independent
- Beeper timer with 1, 2 or 4 kHz frequencies
- Communication interfaces
- Synchronous serial interface (SPI)
- Fast I2C 400 kHz SMBus and PMBus
- USART
- Up to 6 I/Os, all mappable on interrupt vectors
- Development support
- Fast on-chip programming and non-intrusive debugging with SWIM
- Bootloader using USART
- Two ultra-low-power comparators
- One with fixed threshold and another one with rail to rail
- Wakeup capability
- Operating conditions
电路原理图
精选 视频
EDA符号、封装和3D模型
意法半导体 - STM8L050J3
Speed up your design by downloading all the EDA symbols, footprints and 3D models for your application. You have access to a large number of CAD formats to fit with your design toolchain.
Please select one model supplier :
符号
封装
3D模型
质量与可靠性
| 产品型号 | Marketing Status | 包 | 等级规格 | 符合RoHS级别 | Longevity Commitment | Longevity Starting Date | 材料声明** |
|---|---|---|---|---|---|---|---|
| STM8L050J3M3 | 批量生产 | SO-8 | 工业 | Ecopack2 | 10 | 2025-01-01T00:00:00.000+01:00 | |
| STM8L050J3M3TR | 批量生产 | SO-8 | 工业 | Ecopack2 | 10 | 2025-01-01T00:00:00.000+01:00 |
(**) st.com上提供的材料声明表单可能是基于包装系列中最常用的封装的通用文档。因此，它们可能不是100%适用于特定的设备。有关特定设备的信息，请联系 销售支持。
样片和购买
| 产品型号 | 供货状态 | Budgetary Price (US$)*/Qty | 从ST订购 | Order from distributors | 包 | 包装类型 | RoHS | Country of Origin | ECCN (US) | ECCN (EU) | Operating temperature (°C) | Operating Temperature (°C) (max) | ||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 最小值 | 最大值 | |||||||||||||
| STM8L050J3M3TR | | | distributors 无法联系到经销商，请联系我们的销售办事处 | |||||||||||
| STM8L050J3M3 | | | distributors 无法联系到经销商，请联系我们的销售办事处 | |||||||||||
STM8L050J3M3TR 批量生产
STM8L050J3M3 批量生产
