产品概述
描述
The ST8024L is a complete low-cost analog interface for asynchronous Class A, B, and C smartcards. It can be placed between the card and the microcontroller with few external components to perform all supply protection and control functions. The ST8024LCDR and ST8024LCTR are compatible with the ST8024 (with the exception of Vth(ext)rise/fallvalue).
-
所有功能
- Designed to be compatible with the NDS conditional access system (except ST8024LTR)
- ISO 7816, GSM11.11 and EMV 4.2 (payment systems) compatible
- IC card interface
- 3 V or 5 V supply for the ST8024L device (VDD)
- Three specifically protected half-duplex bi-directional buffered I/O lines to card contacts C4, C7 and C8
- Step-up converter for VCCgeneration separately powered by a 5 V ± 20% supply (VDDPand PGND)
- 1.8 V ± 6.5%, 3 V or 5 V ± 5% regulated card supply voltage (VCC) with appropriate decoupling has the following capabilities:
- ICC< 80 mA at VDDP= 4.75 to 6.5 V
- Handles current spikes of 40 nA up to 20 MHz
- Controls rise and fall times
- Filtered overload detection at ~120 mA
- Thermal and short-circuit protection on all card contacts
- Automatic activation and deactivation sequences; initiated by software or by hardware in the event of a short-circuit, card take-off, overheating, VDDor VDDPdropout
- Enhanced ESD protection on card side (>6 kV)
- 26 MHz integrated crystal oscillator
- Built-in debounce on card presence contacts
- One multiplexed status signalOFF
- Non-inverted control of RST via pin RSTIN
- Clock generation for cards up to 20 MHz (divided by 1, 2, 4 or 8 through CLKDIV1 and CLKDIV2 signals) with synchronous frequency changes
- Supply supervisor for spike-killing during power-on and power-off and power-on reset (threshold fixed internally or externally by a resistor divider)
电路原理图
特别推荐
EDA符号、封装和3D模型
意法半导体 - ST8024L
Speed up your design by downloading all the EDA symbols, footprints and 3D models for your application. You have access to a large number of CAD formats to fit with your design toolchain.
Please select one model supplier :
符号
封装
3D模型
质量与可靠性
| 产品型号 | Marketing Status | 包 | 等级规格 | 符合RoHS级别 | Longevity Commitment | Longevity Starting Date | 材料声明** |
|---|---|---|---|---|---|---|---|
| ST8024LACDR | 批量生产 | SO-28 | 工业 | Ecopack2 | - | - | |
| ST8024LACTR | 批量生产 | TSSOP-28 | 工业 | Ecopack3 | - | - | |
| ST8024LCDR | 批量生产 | SO-28 | 工业 | Ecopack1 (*) | - | - | |
| ST8024LCTR | 批量生产 | TSSOP-28 | 工业 | Ecopack3 | - | - | |
| ST8024LTR | 批量生产 | TSSOP-20 | 工业 | Ecopack1 | - | - |
(**) st.com上提供的材料声明表单可能是基于包装系列中最常用的封装的通用文档。因此，它们可能不是100%适用于特定的设备。有关特定设备的信息，请联系 销售支持。
You’re now leaving st.com and will be re-directed to our Partner’s website.
For the latest innovations and solutions from ST, sign up for our newsletters.
样片和购买
| 产品型号 | 供货状态 | Budgetary Price (US$)*/Qty | 从ST订购 | Order from distributors | 包 | 包装类型 | RoHS | Country of Origin | ECCN (US) | ECCN (EU) | Operating temperature (°C) | Operating Temperature (°C) (max) | ||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 最小值 | 最大值 | |||||||||||||
| ST8024LCDR | | | distributors 无法联系到经销商，请联系我们的销售办事处 | |||||||||||
| ST8024LACTR | | | distributors 无法联系到经销商，请联系我们的销售办事处 | |||||||||||
| ST8024LACDR | | | distributors 无法联系到经销商，请联系我们的销售办事处 | |||||||||||
| ST8024LCTR | | | distributors 无法联系到经销商，请联系我们的销售办事处 | |||||||||||
| ST8024LTR | | | distributors 无法联系到经销商，请联系我们的销售办事处 | |||||||||||
ST8024LCDR 批量生产
ST8024LACTR 批量生产
ST8024LACDR 批量生产
ST8024LCTR 批量生产
ST8024LTR 批量生产
