产品概要
描述
The STEVAL-MKI260KA is an adapter kit designed to facilitate the evaluation of the NBP8FD4S battery pressure monitor sensor.
The kit is composed by a generic DIL24 adapter board (STEVAL-MKIGIBV5), a flat cable, and a square PCB mounting the NBP8FD4S battery pressure monitor sensor. The presence of this square PCB ensures to put the sensor board on the system to be measured.
The sensor is soldered in the center of the square PCB to conveniently mount the board on the equipment used for the analysis through double-sided adhesives.
User can mount the board using the holes located in each corner of the PCB.
The STEVAL-MKIGIBV5 can be plugged into a standard DIL-24 socket. The kit provides the complete NBP8FD4S pinout and comes ready to use with the required decoupling capacitors on the VDD power supply line.
The kit is supported by the STEVAL-MKI109D evaluation platform.
The STEVAL-MKI109D includes a high-performance 32-bit microcontroller functioning as a bridge between the sensor and a PC, on which it is possible to use the downloadable MEMS Studio graphical user interface, or dedicated software routines for customized applications.
-
性能一览
- User-friendly NBP8FD4S board
- Complete NBP8FD4S pinout for a standard DIL 24 socket
- Fully compatible with STEVAL-MKI109D evaluation platform
- RoHS compliant
