产品概要
描述
The purpose of this design is to demonstrate the features of the VN751PT high-side driver.
The application offers robustness and complies with EMC industrial standards.
It implements short-circuit/overload protection and thermal management as well, achieving best in class MTBF values.
The reference design is suitable for use in programmable logic controllers (PLCs) as well as to drive generic loads which require up to 2.5 A of nominal current (the typical current limitation is 4.5 - 5 A).
Thanks to the very low RDSon (only 60 mO Typ. @ 25 °C) the device allows very low power consumption during the operation and for this reason it represent an ideal solution for IP65 / IP67 requirements. The device is compliant with IEC 61131-2 (programmable controllers international standard).
-
性能一览
- RoHS compliant
- Transil addition between TRIAC A2-G terminals
- Overvoltage protection is not implemented on the board but some solder pads are available to implement it in two different ways:
- Free development area with hole matrix available for application breadboard adaptation
- 3 independent application programs
Hand dryer with infrared sensor and T1235H-6T switch Bathroom fan with humidity sensor and ACS108 switch Multi-entrance room controller with push button and BTB08-600SW switch - Capacitive power supply (680 nF capacitor EPCOS B32923C3684
5 V ±10% Average output current: 16 mA Standby power losses < 0.3 W @ 230 V - Two potentiometers for setting sensor sensitivity and TRIAC turn-off delay
- ICC connector for software adjustment
- Varistor addition between mains voltage
- Program selector (U2)
特别推荐
所有资源
| Resource title | 版本 | Latest update | Actions | Details | 下載 |
|---|
Board Manufacturing Specifications (1)
| Resource title | 版本 | Latest update | Actions | Options | ||
|---|---|---|---|---|---|---|
| ZIP | 1.0 | 01 Aug 2015 | 01 Aug 2015 |
BOM (1)
| Resource title | 版本 | Latest update | Actions | Options | ||
|---|---|---|---|---|---|---|
| 1.0 | 01 Aug 2015 | 01 Aug 2015 |
Schematic Pack (1)
| Resource title | 版本 | Latest update | Actions | Options | ||
|---|---|---|---|---|---|---|
| 1.0 | 01 Aug 2015 | 01 Aug 2015 |
Quality and Reliability
| Part Number | Marketing Status | Package | Grade | 符合RoHS级别 | WEEE Compliant | Longevity Commitment | Longevity Starting Date | Material Declaration** |
|---|---|---|---|---|---|---|---|---|
| STEVAL-IFP005V2 | Active 产品已量产 | CARD | Industrial | Ecopack2 | - | - | - | |
STEVAL-IFP005V2
Package:
CARDMaterial Declaration**:
(**) st.com上提供的材料声明表单可能是基于包装系列中最常用的封装的通用文档。因此，它们可能不是100%适用于特定的设备。有关特定设备的信息，请联系 销售支持。
