产品概述
描述
The STEVAL-IDB013V1 evaluation platform is designed to help the user develop and test Bluetooth® Low Energy applications. It uses the low-power BlueNRG-LPS system-on-chip in combination with inertial and environmental MEMS sensors and digital MEMS microphone, and various interface buttons and LEDs.
The BlueNRG-LPS features a 64 MHz, 32-bit Arm Cortex®-M0+ core, 192 KB programmable flash memory, 24 KB SRAM, MPU, and an extensive peripheral set (6x PWM, I²C, SPI/I2S, USART, LPUART, 12-bit ADC SAR).
The BlueNRG-LPS is compliant with the Bluetooth® Low Energy specification, supporting: master, slave, simultaneous master-and-slave roles, data length extension, 2 Mbps, long range, extended advertising and scanning, channel selection algorithm #2, GATT caching, LE Ping procedure, LE power control and path loss monitoring, direction finding (angle of arrival/angle of departure) features.
Serial communication with a PC and three power options (USB only, battery only, external power supply) allow complex application development and testing flexibility.
-
所有功能
- Bluetooth® Low Energy evaluation board based on the BlueNRG-LPS (BlueNRG-332VC)
- Bluetooth® Low Energy 5.2 certified SoC in WLCSP36 package:
- Master, slave, and simultaneous master-and-slave roles
- Long range, 2 Mbps data rate, advertising extensions, periodic advertising, CSA#2, GATT caching, LE ping procedure, periodic advertising and periodic advertising sync transfer, LE L2CAP connection-oriented channel, LE power control, and path loss monitoring
- Supports direction finding with angle of arrival (AoA) and angle of departure (AoD)
- Uncompromised low-power radio performances:
- Up to +7 dBm programmable output power (at antenna connector)
- Excellent receiver sensitivity (-95 dBm @ 1 Mbps, -101 dBm @ 125 kbps - long range)
- Very low power consumption: 3.4 mA Rx @ sensitivity level, and 4.3 mA Tx @ +0 dBm
- Integrated 32-bit core Arm Cortex®-M0+, 64 MHz 192-Kbyte flash memory, 24-Kbyte SRAM, MPU, extensive peripheral set
- Chip antenna, IPD, UFL connector for measuring equipment and Arduino R3 connectors
- Three power options: USB cable, battery, and external power supply
- Associated BlueNRG-LPS development kit software package (STSW-BNRGLP-DK) including firmware and documentation
- 3 user LEDs and 2 user buttons
- MEMS digital accelerometer/gyroscope
- MEMS digital pressure/temperature sensor
- Embedded CMSIS-DAP debugger and drag&drop programming support
- RoHS compliant
您可能还会喜欢...
特别推荐
所有资源
| 资源标题 | 版本 | 更新时间 |
|---|
Board Manufacturing Specifications (1)
| 资源标题 | 版本 | 更新时间 | ||
|---|---|---|---|---|
| ZIP | 1.0 | 09 Oct 2023 | 09 Oct 2023 |
物料清单 (1)
| 资源标题 | 版本 | 更新时间 | ||
|---|---|---|---|---|
| 1.0 | 09 Oct 2023 | 09 Oct 2023 |
Schematic Pack (1)
| 资源标题 | 版本 | 更新时间 | ||
|---|---|---|---|---|
| 1.0 | 09 Oct 2023 | 09 Oct 2023 |
质量与可靠性
| 产品型号 | Marketing Status | 包 | 等级规格 | 符合RoHS级别 | WEEE Compliant | 材料声明** |
|---|---|---|---|---|---|---|
| STEVAL-IDB013V1 | 批量生产 | CARD | 工业 | Ecopack2 | Yes | |
STEVAL-IDB013V1
Package:
CARDMaterial Declaration**:
(**) st.com上提供的材料声明表单可能是基于包装系列中最常用的封装的通用文档。因此，它们可能不是100%适用于特定的设备。有关特定设备的信息，请联系 销售支持。
样片和购买
| 产品型号 | 供货状态 | Budgetary Price (US$)*/Qty | 从ST订购 | Order from distributors | 包 | 包装类型 | RoHS | Country of Origin | ECCN (US) | ECCN (EU) | 供应商 | 核心产品 | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| STEVAL-IDB013V1 | | | distributors 无法联系到经销商，请联系我们的销售办事处 |
|
|
STEVAL-IDB013V1 批量生产
