产品概述
描述
The SATEL-VL53L4CD package includes two breakout boards, which can be easily integrated into the customer's devices.
The PCB section that embeds the VL53L4CD module is perforated. The developers can then break off the mini-PCB and use it in a 3.3 V supply application via flying wires.
This makes it easier to integrate the SATEL-VL53L4CD breakout boards into the development and evaluation devices thanks to their small size.
-
All features
- VL53L4CD Time-of-Flight high-accuracy proximity sensor
- High-performance proximity ranging, independent of the target size and reflectance
- From 0 to 1300 mm with full field of view (FoW)
- Short distance linearity down to 1 mm
- Divisible board that can be used as a mini-PCB breakout board, easy to integrate into the customer's device
- Two breakout boards available in the package
- Compatible with X-NUCLEO-53L4A1
特别推荐
所有资源
| Resource title | 版本 | Latest update | Actions | Details | 下載 |
|---|
Board Manufacturing Specifications (1)
| Resource title | 版本 | Latest update | Actions | Options | ||
|---|---|---|---|---|---|---|
| ZIP | 1.0 | 02 Feb 2022 | 02 Feb 2022 |
BOM (1)
| Resource title | 版本 | Latest update | Actions | Options | ||
|---|---|---|---|---|---|---|
| 1.0 | 02 Feb 2022 | 02 Feb 2022 |
Schematic Pack (1)
| Resource title | 版本 | Latest update | Actions | Options | ||
|---|---|---|---|---|---|---|
| 1.0 | 02 Feb 2022 | 02 Feb 2022 |
CAD Design Files (1)
| Resource title | 版本 | Latest update | Actions | Options | ||
|---|---|---|---|---|---|---|
| ZIP | 1.0 | 21 Sep 2023 | 21 Sep 2023 |
Quality and Reliability
| Part Number | Marketing Status | Package | Grade | 符合RoHS级别 | WEEE Compliant | Material Declaration** |
|---|---|---|---|---|---|---|
| SATEL-VL53L4CD | Active 产品已量产 | CARD | Industrial | Ecopack2 | Yes | |
SATEL-VL53L4CD
Package:
CARDMaterial Declaration**:
(**) st.com上提供的材料声明表单可能是基于包装系列中最常用的封装的通用文档。因此，它们可能不是100%适用于特定的设备。有关特定设备的信息，请联系 销售支持。
