Software for STEVAL-LLL012V1 smart LED driver with high power factor using BLE mesh network for indoor lighting

获取软件 下载数据摘要



The STSW-LLL012FW is dedicated to LED lighting control in a smart home scenario based on BLE mesh wireless networking technology using the STEVAL-LLL012V1 evaluation kit and enabling remote dimming plus on/off control from a single Android or iOS phone device, together with the ST BLE Mesh mobile app.

The firmware runs on the BLUENRG-M2SP integrated wireless module on the STEVAL- LLL012V1, featuring the HVLED001B high brightness LED driver.

STSW-LLL012V1FW is available for free download with developer-friendly license terms.

You can use it to test the BLUENRG-M2SP connectivity and HVLED001B LED power control functionality or to develop your own custom solutions.

  • 所有功能

    • Specifically designed to support smart home LED lighting applications and run on BLUENRG-M2SP wireless module
    • BLE wireless mesh networking functionality for remote control of multiple nodes
    • ON/OFF LED and dimming control capability with the support of ST BLE Mesh Android/iOS mobile app
    • 1% dimming resolution plus on/off control
    • Developer-friendly license terms
