FP-SNS-STBOX1 is an STM32Cube function pack for the Pro Mode of the SensorTile.box wireless multi sensor development kit, STWIN.box - SensorTile, and for Sensortile.box Pro multi-sensors and wireless connectivity development kit for any intelligent IoT node. Wireless Industrial Node Development Kit, which helps you to build custom applications.

The package includes pressure, relative humidity, temperature, accelerometer, gyroscope and magnetometer sensors, as well as an analog and digital microphones, and the SPBTLE-1S Bluetooth low energy system-on-chip application processor.

With the STEVAL-MKSBOX1V1, STEVAL-STWINBX1, and STEVAL-MKBOXPRO kits with BLE connectivity, you can monitor and log the algorithm output and sensor data using the STBLESensor app.

The software runs on the STM32 microcontroller and includes all the necessary drivers for the STEVAL-MKSBOX1V1, STEVAL-STWINBX1, and STEVAL-MKBOXPRO evaluation kits.

  • 所有功能

    • Complete samples on how to:
      • use ultra-low power implementation based on an RTOS for transmitting the data via BLE connectivity
      • use the dual bank flash feature for rollback after a FOTA update
      • program the LSM6DSOX (for STEVAL-MKSBOX1V1), ISM330DHCX (for STEVAL-STWINBX1), and LSM6DSV16X (for STEVAL-MKBOXPRO) machine learning core (MLC) or theirs finite state machine (FSM), control the output of theirs registers and transmit the results via BLE
      • easily send the data via BLE
      • save the sensor data to the SD card
      • visualize the sensor data with the Unicleo-GUI via PC serial terminal
    • Compatible with STBLESensor application for Android/iOS, to perform sensor and audio data reading, motion algorithm feature demo, and FOTA via BLE connectivity
    • Sample implementation available for the STEVAL-MKSBOX1V1, STEVAL-STWINBX1, and STEVAL-MKBOXPRO kits
    • Easy portability across different MCU families, thanks to STM32Cube
    • Free, user-friendly license terms
