Key Benefits
Flexible configuration & control
Programmable power rails, sequencing, and diagnostics via SPI for customized system operation
Advanced safety, diagnostics & reliability
Integrated monitoring, fail-safe functions, thermal protection, and automotive-grade robustness.
Automotive power management with integrated CAN-FD communication
Highly integrated multi-output PMIC with dedicated communication support for advanced automotive ECUs
描述
The SPSB100GS is a fully integrated automotive power management system IC, specifically designed for highly integrated application processors (e.g. Stellar G and P MCU families), offering low-power mode and high-current capability. The device comes with enhanced system power supply functionality and a CAN-FD physical communication layer (available only on the SPSB100GS version).
It combines three switch-mode power supplies together with two integrated linear voltage regulators. The device further integrates two wake-up inputs and advanced fail-safe functionalities. The device also embeds a Long Duration Timer up to 180 days.
The boost controller is intended to sustain cold cranking pulses, start-stop, and weak battery conditions.
Different combinations make it possible to supply the system microcontroller, the integrated CAN-FD transceiver (only for the SPSB100GS version), and external peripheral loads and sensors in several adjustable voltage and current ranges. The SPSB100GS and the SPSB100GBS Sare delivered out of STMicroelectronics factory with default values (rails, power-up and -down sequences) stored in the USER-NVM space as reported in System Supply Configuration 1, but can be also re-programmed by customers based on different application needs.
The STMicroelectronics standard SPI interface allows for control and diagnosis of the device and enables generic software development.
The device offers a set of features to support applications that need to fulfill functional safety requirements as defined by Automotive Safety Integrity Level (ASIL).
-
性能一览
- AEC-Q100 grade 1 qualified
- Two configurable (6.5 V, 5 V, 3.3 V) buck converters (up to 3.0 A ) @ 2.4 MHz or 400 kHz
- One buck converter dedicated to the core power supply at 1.02V (up to 6 A) @ 2.4 MHz, with fine-tuning configurability from 0.99 V to 1.05 V
- Overcurrent detection and limitation for all bucks
- Integrated soft-start on buck stages
- Boost controller 6 - 9 V with a max current capability of 3.5 A @ 400 kHz, for sustaining permanently low battery conditions and deep cranking pulses with boost modes
- One 5 V voltage regulator (120 mA) for CAN-FD supply
- One configurable (5 V or 3.3 V) low drop voltage tracker of buck regulator (10 mA)
- One high-side driver for contact monitoring (RON = 55 Ω) with open-load and overcurrent diagnosis
- Dedicated interrupt pin for failure communication
- Device can operate in low-power mode
- Very low quiescent current in deep sleep state
- MCU reset generator
- Configurable window watchdog with an extended long open window up to 9 s, with maskable function and enable/disable function through NVM bits
- 1 CAN-FD transceiver (ISO 11898-2/2016 compliant), which can be deactivated via SPI, with local failure and bus failure diagnosis
- Device contains temperature warning and protection
- Thermal clusters
- A/D conversion of supply voltages and internal temperature sensors
- STMicroelectronics standard serial peripheral interface (32-bit / ST_SPI) including 4-bit CRC
- One fail-safe output
- One input pin supporting static and dynamic error signal reporting
- Programmable periodic system wake-up feature
- Programmable periodic system wake-up feature extended up to 180 days (Very Long Duration Timer)
- Documentation available for customers that need support when dealing with ASIL requirements as per ISO26262
