The ESDCAN series improves the quality of protection for CAN-FD (flexible datarate), CAN SIC (signal improvement capability) and even CAN XL (extra-long) transceivers without hurting the capacitance budget and reduces the PCB size by 4 compared to conventional solutions.
The autonomous driving megatrend induces a higher electronics content in the car. It deeply modifies the E/E architecture with the coming of Zone Control Units (ZCU) and Vehicle Computer Units (VCUs). These high-density boards can concentrate tens of CAN links making the need to protect CAN transceivers against electrostatic discharge (ESD) and ISO 7637-3 pulses, and requiring high integrated protection solutions. ST offers a wide range of AEC-Q101 CAN protection devices for passenger cars (12 V battery) or commercial vehicles (24 V battery) covering CAN, CAN-FD, CAN-FD SIC, FlexRay and even CAN XL communication protocols. Our devices are housed in 3-lead SOT23 and SOT323 packages as well as in our new extra-small (1.1 x 1.0 mm) wettable flank 3-lead QFN (DFN1110) package allowing AOI (Automatic Optical Inspection).
Key features
- Dual-line ESD and EOS protection
- Bidirectional devices
- Maximum pulse current: 5.5 A (8/20 μs)
- Stand-off voltage: from 24 V up to 36 V
- Low leakage current: 100 nA (max.)
- Compliant with:
- ISO 7637-3a and 3b
- ISO 10605 / IEC 61000-4-2: up to 30 kV air and contact
- ISO 16750-2
- AEC-Q101
Benefits
- ESD and EOS plug-and-play protection solutions for CAN transceivers already approved by various car makers
- Enables high-density PCBs thanks to tiny, compact packages (SOT323-3L, QFN-3L, and DFN1110)
- Design and layout flexibility with wide range of products with low capacitance
- Covers most mission profiles with reliability tests performed at maximum Tj =175°C for CAN-FD, Flexray and various voltages to fit car and truck requirements.
Application examples
CAN (Controller Area Network)CAN-FD (Flexible Datarate)
CAN-FD SIC (Signal Improvement Capability)
CAN XL (Extra-Long)
FlexRay
USB 2.0 and IEEE 100BASE-T1
